Mean Well TDR-960-48
Article number:
TDR-960-48
Article GTIN:
4711287422510
Downloads
AC-DC Industrial 3-phase DIN rail power supply; Output 48Vdc at 20A; metal case; 2 phase operation possible; current sharing 3+1
Properties
- Series: TDR-960
- Brand: Mean Well
- Dimensions LxWxH (mm): 203x161x182 mm
- Warranty: 36 Months Bring-In
- Gross weight: 2500
- Type: AC-DC
- Form factor: DIN rail
- Mounting method: DIN-rail mount
- Min. output voltages (V): 48
- Max. output voltage (V): 48
- Number of output voltages: 1
- Max output power (W): 960
- Input voltage (V): 340 - 550
- Min. input voltage: 340
- Max. input voltage (V): 550
- Max. output current (A): 20
- Number of output currents: 1
- IP rating: No IP assigned
- LED driver: No
- Dimming technologies: No Dimming
- Control signals: No control signals
- Carbon footprint (kgCO2e/pcs): 30.77
