Mean Well LDD-350LW
Article number:
LDD-350LW
Article GTIN:
4711287480381
Downloads
DC-DC Step down LED driver Constant Current (CC); Input 9-36Vdc; Output 0.35A at 2-32Vdc; Wired in- output; Dimming with PWM and remote ON/OFF
Properties
- Series: LDD-L
- Brand: Mean Well
- Dimensions LxWxH (mm): 8x24x10 mm
- Warranty: 12 Months Bring-In
- Gross weight: 10
- Type: DC-DC
- Form factor: Module
- Mounting method: PCB Mount
- Min. output voltages (V): 32
- Max. output voltage (V): 32
- Number of output voltages: 1
- Max output power (W): 11
- Input voltage (V): 9 - 36
- Min. input voltage: 9
- Max. input voltage (V): 36
- Max. output current (A): 0.35
- Number of output currents: 1
- IP rating: No IP assigned
- LED driver: Yes
- Dimming technologies: PWM
- Control signals: No control signals
- Carbon footprint (kgCO2e/pcs): 0.06
