Mean Well HLG-480H-24A
Article number:
HLG-480H-24A
Article GTIN:
4711287451367
Downloads
AC-DC Single output LED Driver Mix Mode (CV+CC) with built-in PFC; Output 24VDC at 20A; Adjust CC/CV with Potentiometer; IP65; Cable output
Properties
- Series: HLG-480H
- Brand: Mean Well
- Dimensions LxWxH (mm): 262x125x43.8 mm
- Warranty: 12 Months Bring-In
- Gross weight: 2890
- Type: AC-DC
- Form factor: Enclosed
- Mounting method: Chasis mount
- Min. output voltages (V): 24
- Max. output voltage (V): 24
- Number of output voltages: 1
- Max output power (W): 480
- Input voltage (V): 90 - 305
- Min. input voltage: 90
- Max. input voltage (V): 305
- Max. output current (A): 20
- Number of output currents: 1
- IP rating: IP65
- LED driver: Yes
- Dimming technologies: Analog, Potentiometer
- Control signals: No control signals
- Carbon footprint (kgCO2e/pcs): 29.4
