Mean Well HLG-240H-48
Article number:
HLG-240H-48
Article GTIN:
4711287450711
Downloads
AC-DC Single output LED Driver Mix Mode (CV+CC) with built-in PFC; Output 48Vdc at 5A; IP67; Cable output
Properties
- Series: HLG-240H
- Brand: Mean Well
- Dimensions LxWxH (mm): 310x96x52 mm
- Warranty: 12 Months Bring-In
- Gross weight: 1240
- Type: AC-DC
- Form factor: Enclosed
- Mounting method: Chasis mount
- Min. output voltages (V): 48
- Max. output voltage (V): 48
- Number of output voltages: 1
- Max output power (W): 240
- Input voltage (V): 90 - 305
- Min. input voltage: 90
- Max. input voltage (V): 305
- Max. output current (A): 5
- Number of output currents: 1
- IP rating: IP67
- LED driver: Yes
- Dimming technologies: No Dimming
- Control signals: No control signals
- Carbon footprint (kgCO2e/pcs): 14.29
