Mean Well HDR-150-12
Article number:
HDR-150-12
Article GTIN:
4711287421841
Downloads
AC-DC Ultra slim DIN rail power supply; Input range 85-264VAC; Output 12VDC at 11.3A
Properties
- Series: HDR-150
- Brand: Mean Well
- Dimensions LxWxH (mm): 118x99x66 mm
- Warranty: 12 Months Bring-In
- Gross weight: 350
- Type: AC-DC
- Form factor: DIN rail
- Mounting method: DIN-rail mount
- Min. output voltages (V): 12
- Max. output voltage (V): 12
- Number of output voltages: 1
- Max output power (W): 150
- Input voltage (V): 85 - 264
- Min. input voltage: 85
- Max. input voltage (V): 264
- Max. output current (A): 11.3
- Number of output currents: 1
- IP rating: No IP assigned
- LED driver: No
- Dimming technologies: No Dimming
- Control signals: No control signals
- Carbon footprint (kgCO2e/pcs): 5.15
