Mean Well CSP-3000-400
Article number:
CSP-3000-400
Article GTIN:
4711287420981
Downloads
AC-DC Single output enclosed power supply with PFC; Output 400Vdc at 7.5A; remote ON/OFF
Properties
- Series: CSP-3000
- Brand: Mean Well
- Dimensions LxWxH (mm): 429x250x130 mm
- Warranty: 12 Months Bring-In
- Gross weight: 3450
- Type: AC-DC
- Form factor: Enclosed
- Mounting method: Chasis mount
- Min. output voltages (V): 400
- Max. output voltage (V): 400
- Number of output voltages: 1
- Max output power (W): 3000
- Input voltage (V): 180 - 264
- Min. input voltage: 180
- Max. input voltage (V): 264
- Max. output current (A): 7.5
- Number of output currents: 1
- IP rating: No IP assigned
- LED driver: No
- Dimming technologies: No Dimming
- Control signals: No control signals
- Carbon footprint (kgCO2e/pcs): 37.47
